SVR1000-C621

·  英特尔 C621 工业母板

·  LGA3647 2nd Xeon Scalable 处理器

·  最大支持192GB DDR4内存

·  双英特尔千兆网口

·  2个串口,6个USB3.0+ 5个USB2.0

趣游在线登录·  2个PCI-E 16X,2个PCI-E 8X,1个PCI

LGA 3647 2nd Intel Xeon Scalable Processor工业母板,双GbE网口, 2PCIE 16X/2PCIE 8X/PCI













CPU

CPU

2nd Intel Xeon Scalable Processor

Socket

LGA3647

Chipset

Intel C621

DRAM

Frequency

DDR4 up to 2933MHz

Capacity

Up to 192GB

Socket

6 x 288-pin RDIMM

Display

Graphics

Need independent Graphics card

Mutil-display

By Graphics card

LAN

2 x Intel GbE (i210-AT)

Audio

ALC887 w /Line-out/Mic

Watchdog

Programmable from 1 to 255 Sec

Storage

SATA

6 x SATA3.0

mSATA

N/A

M.2 SSD

1 x M.2 2280 M key (PCIe Gen3 x 4 NVMe/SATA)

I/O



Serial

2 x RS232

LPT

N/A

USB

6 x USB3.0 + 5 x USB2.0

GPIO

N/A

PS/2

N/A

TPM

Opt.

SIM

N/A

Expansion

Slot

PCIe x16

2  (Full Signal, Ver: 3.0)

PCIe 8X

2  (Ver: 3.0)

PCIe 4X

N/A

PCI

1

Power

Type

ATX

Form Factor

305mm x 244mm (ATX )

Environment

Operation Temp& Humidity

0~60/10~90%

Non-condensing

Storage Temp & Humidity

-40~85/10~90%

Non-condensing

Certification

EMC

CE / FCC

O.S

Windows 10 IoT Enterprise LTSB (64-bit)

Windows Server 2012 R2

Windows Server 2016

Ubuntu 18.04


Model                          Description

SVR1000-C621                 Intel C621 ATX w/2GbE/2COM/11USB/2PCIE 16X/2PCIE 8X/PCI
