SYM86373VGGA
· LGA1150 英特尔酷睿4代i3/i5/i7 处理器
· 英特尔 B85 芯片组
· 2 个 240pin DDR3 1600/1333MHz内存，最大支持16GB
· 2 个 SATA 3.0, 2 个 SATA 2.0
· 双千兆网口
· 6 个串口，2个 USB3.0, 9 个 USB2.0接口
· 2 个 ISA, 3 个 PCI , 1个PCI-E 4X，1个PCI-E 16X扩展槽
LGA1150 英特尔酷睿4代 i3/i5/i7 ATX母板，双GbE，2xISA
CPU
| CPU | 4th Intel Core i3/i5/i7/Pentium/Celeron Processor (Haswell) | ||
Socket | LGA1150 | |||
Chipset | Intel B85 PCH | |||
BIOS | AMI UEFI | |||
DRAM | Frequency | DDR3 -1600/1333MHz | ||
Capacity | Up to 16GB | |||
Socket | 2 x 240-Pin DIMM | |||
Display | Graphics | Intel HD Graphics support DX11.1 & OpenCL 1.2 | ||
DRAM | Up to 1.7GB | |||
VGA | 1, up to 1920x1200@60Hz | |||
DVI-D | 1, Up to 1920x1200@60Hz | |||
Multi-display | 2 Independent Display | |||
LAN | 2 x Realtek GbE (RTL8111F) | |||
Audio | Realtek ALC662 W/Line-Out /Mic/Line-in | |||
Watchdog | Programmable from 1 to 255 Sec/Min | |||
Storage | SATA | 2 x SATA3.0 + 2 x SATA2.0 | ||
mSATA | 1 （Share w/Mini PCIe） | |||
RAID | N/A | |||
I/O | Serial | 6 x RS232 (COM1 W/RS232/422/485) | ||
LPT | 1 | |||
USB | 2 x USB3.0 + 9 x USB2.0 | |||
GPIO | 4-In , 4-Out | |||
PS/2 | 1 | |||
Expansion Slot | PCIe 16X | 1 | ||
PCIe 4X | 1 | |||
PCI | 3 | |||
ISA | 2 | |||
Mini PCIe | 1 (Share w/mSATA) | |||
Power | Type | ATX Power | ||
Form Factor | 305mm x 220mm (ATX ) | |||
Environment
| Operation Temp& Humidity | 0~60℃/10~90% Non-condensing | ||
Storage Temp & Humidity | -20~80℃/10~90% Non-condensing | |||
Certification | EMC | CE / FCC | ||
O.S | Windows XP Pro/Windows 7 32/64-Bit Windows 8.1 64-Bit/Windows 10/ Linux (Kernel 3.0+) | |||
Model Description
SYM86373VGGA Intel B85 ATX Board w/VGA/DVI/2GbE/6COM/LPT/11USB/HD Audio/2ISA
