SYM86456V4GA
· 英特尔 Skylake & Kabylake Q170 Micro-ATX主板
趣游在线登录· LGA1151英特尔酷睿六/七代 i3/i5/i7/奔腾/赛扬处理器
· 最大支持64GB DDR4内存
· 四个英特尔千兆网口
· 6 个 串口，6 个 USB2.0+ 6 个 USB3.0
· 2 个 PCI-E 16X，2 个 PCI-E 4X 扩展槽
· 支持独立三显
· 支持RAID 0/1/5/10
LGA 1151 Intel Core i3/i5/i7 Micro-ATX 母板，带VGA/DVI-D/DP，四网口
Processor
| CPU | 6th&7th Intel Core i3/i5/i7/Pentium/Celeron Processor |
Socket | LGA1151 | |
Chipset | Intel Q170 PCH | |
BIOS | AMI UEFI | |
DRAM | Technology | DDR4-2133/2400MHz |
Capacity | 64GB | |
Socket | 4 x 288-Pin DIMM | |
Display | Graphics | Intel HD Graphics |
Graphics Memory | Share System memory up to 1.7GB SDRAM | |
VGA | 1, Up to 1920 x 1200@60Hz | |
DVI-D | 1, Up to 1920 x 1200@60Hz | |
DP | 1, Up to 4096 x 2106@60Hz | |
Mult-Display | 3 Independent displays | |
LAN | 4 x Intel GbE LAN (3 x i211-AT+ i219-LM) | |
Audio | Realtek ALC888 w/Line-Out & MIC | |
Watchdog | Programmable from 1 to 255 Sec | |
Storage | SATA | 5 x SATA3.0 |
mSATA | N/A | |
M.2 | 2260/2280 , M.Key SATA3.0/PCIe Gen3 x2 NVMe | |
RAID | RAID 0/1/5/10 | |
I/O | COM Port | 6 x RS232 (COM1&COM2 w/ RS232/422/485) |
USB | 6 x USB3.0+ 6 x USB2.0 | |
GPIO | 4 x In , 4-Out | |
PS/2 | 1 | |
TPM | TPM2.0/1.2 (Optional., MOQ Required) | |
Expansion Slot | PCIe x16 | 2 (Ver:3.0) (1 x16 signal or 2 x8 signals) |
PCIe 4X | 2 (Ver:3.0) | |
PCIe 1X | N/A | |
PCI | N/A | |
Mini PCIe | N/A | |
Power | Type | ATX |
Form Factor | 244mm x 244mm | |
Environment | Operation Temp& | 0~60℃/10~90% Non-condensing |
Storage Temp & Humidity | -40~80℃/10~90% Non-condensing | |
Certification | EMC | CE / FCC |
Model Description
SYM86456V4GA Intel Q170 Micro-ATX w/VGA/DVI-D/DP/4GbE/6COM/12USB/HDA
