SYM86601VGGA-Q370
趣游在线登录· 英特尔 Coffee lake Q370 ATX主板
趣游在线登录· LGA1151英特尔酷睿八代 i3/i5/i7/奔腾/赛扬处理器
趣游在线登录· 最大支持64GB DDR4内存
趣游在线登录· 双英特尔千兆网口
· 6个串口，6个USB2.0+ 4个USB3.0+2个USB3.1
· 2个PCI-E 16X，3个PCI-E 4X，1个PCI-E 1X，1个PCI
· 支持RAID 0/1/5/10
· 支持独立三显
LGA 1151 8th Intel Core i3/i5/i7 ATX 母板，带VGA/2DP，双GbE网口
Processor | CPU | 8th Intel Core i3/i5/i7/Pentium/Celeron Processor |
Socket | LGA1151 | |
Chipset | Intel Q370 PCH | |
BIOS | AMI UEFI | |
DRAM | Technology | DDR4-2400/2666MHz |
Capacity | 64GB | |
Socket | 4 x 288-Pin DIMM | |
Display | Graphics | Intel HD Graphics |
Graphics Memory | Share System memory up to 1.7GB SDRAM | |
VGA | 1, Up to 1920 x 1200@60Hz | |
DVI-D | N/A | |
DP | 2, Up to 4096 x 2160@60Hz | |
Mult-Display | 3 Independent displays | |
LAN | 2 x Intel GbE (i211-AT+ i219-LM) | |
Audio | Realtek ALC888 w/Line-Out & MIC | |
Watchdog | Programmable from 1 to 255 Sec | |
Storage | SATA | 5 x SATA3.0 (One share w/mSATA) |
mSATA | 1 (share w/SATA3.0) | |
M.2 | 2242/2260/2280 M key (PCIe Gen3 x 2 NVMe) | |
RAID | RAID 0/1/5/10 | |
I/O | Serial | 6 x RS232 (COM1&COM2 w/ RS232/422/485) |
USB | 2 x USB3.1 + 4 x USB3.0+ 6 x USB2.0 | |
GPIO | 4 x In , 4-Out | |
PS/2 | 1 | |
TPM | N/A | |
Expansion Slot | PCIe 16X | 2 (Ver:3.0) (1 x16 signal or 2 x8 signals) |
PCIe 4X | 3 (Ver:3.0) | |
PCIe 1X | 1 (Ver:3.0) | |
PCI | 1 | |
Mini PCIe | 2 ( One share w/mSATA) | |
Power | Type | ATX |
Form Factor | 305mm x 244mm | |
Environment | Operation Temp& Humidity | 0~60℃/10~90% Non-condensing |
Storage Temp & Humidity | -40~80℃/10~90% Non-condensing | |
Certification | EMC | CE / FCC |
Model Description
SYM86601VGGA-Q370 Intel Q370 ATX support 8th Intel Core i3/i5/i7/Pentium/Celeron, w VGA/2DP/2GbE/6COM/12USB/HDA
